AutoEnginuity Total Ford scantool bundle - SP03

AUTOENGINUITY'S SCAN TOOL IS A HARDWARE AND SOFTWARE COMBINATION FOR WINDOWS PC, WINDOWS POCKET PC 2003SE/2005, AND WINDOWS MOBILE 5/6 COMPLIANT PDAS, AND PALM COMPUTING DEVICES. AUTOENGINUITY'S SCAN TOOL WAS DESIGNED TO BE AS EASY TO LEARN—AS IT IS POWERFUL. SCAN TOOL COMES WITH AN AUTOMATED INSTALLATION PROCESS, A COMPLETE AND COMPREHENSIVE USER GUIDE, AND AN EASY-TO-USE INTERFACE. YOU WON'T HAVE TO SPEND VALUABLE TIME LEARNING ANOTHER PIECE OF SOFTWARE, YOU CAN FOCUS ON WHAT'S IMPORTANT—SERVICING THE VEHICLE.

ALTHOUGH FORD DOES IMPLEMENT THE LARGEST SUBSET OF THE OBDII STANDARD, THE TYPICAL VEHICLE ONLY SUPPORTS 20 - 40 SENSORS AND IS LIMITED TO EMISSIONS POWERTRAIN. USING THE ENHANCED FORD INTERFACE, A TYPICAL FORD VEHICLE WILL SUPPORT 200 - 300 SENSORS WITHIN HALF A DOZEN SYSTEMS; THAT'S ESSENTIAL SYSTEMS SUCH AS ABS, AIRBAGS, GEM, ICM, ETC.

SUPPORT FOR 7,900 SENSORS SELECTED FROM 122 SYSTEMS. INCLUDES ISO, SCP, CAN, MCAN, AND CAN 14229 CONTROLLERS. THE FORD ENHANCED INTERFACE HAS SUPPORT FOR FORD OF EUROPE DIESEL MODELS SUCH AS KA, MONDO, GALAXY, FAIRLANE, ETC.

FORD ENHANCED HAS SUPPORT FOR NON-CAN AND CAN 1300 BI-DIRECTIONAL COMMANDS AND DOZENS OF SYSTEM-LEVEL TESTS. WITH BI-DIRECTIONAL CONTROLS, YOU WILL NO LONGER BE RELEGATED TO BEING JUST AN OBSERVER IN THE OPERATION OF THE VEHICLE--NOW YOU CAN TAKE CONTROL OF ITS OPERATION.

SYSTEM TESTS:

• PATS TIMED KEY PROGRAMMING ('96 - '08)
• KOEO, KOER, POWER BALANCE (CAN-BASED MODELS)
• EVAP BAY TEST, SERVICE BLEED (NON-CAN SUPPORT NOT AVAILABLE WITH PROLINE CURRENTLY)
• BUZZ INJECTOR TEST
• CYLINDER CONTRIBUTION TEST
• SWITCH TEST, LOW - AND HIGH SPEED FAN
• GLOW PLUG TEST
• SYSTEM SELF-TEST, ALL OUTPUTS ON/OFF
• INJECTOR CODING (1.8L AND 2.0L)
• KAM RESET, MISFIRE MONITOR
• NEUTRAL PROFILE CORRECTION
• TIRE SIZE PROGRAMMING UP TO 40" ('99-'03 7.3L, AND '04-'07 6.0L TRUCKS)
• IVD INITIALIZATION
• STEERING ANGLE / YAW RATE / ACCELERATION SENSOR RESET ('03 EXPLORER AND LINCOLN LS)
• PASSENGER SEAT RE-ZERO AND PASSENGER WEIGHT RESET
• POWER SEAT CALIBRATION TEST
• AUDIO NETWORK COMMUNICATION TEST
• VEHICLE IN-MOTION IO TEST
• FRONT/REAR WIPER SELF-TEST
• DIESEL PARTICULATE FILTER RESET
• CLEAR EGR ADAPTIVE TABLES
• CLEAR FUEL INJECTOR ADAPTIVE TABLES

*NOTE: F450/F550/F650/F750 ARE NOT LIGHT DUTY TRUCKS AND WILL HAVE LIMITED OR NO SUPPORT.

*MCAN BODY CONTROLLERS REQUIRE ST06 PROLINE HARDWARE.

DOES NOT SUPPORT ANY UBP CONTROLLERS AS ON SOME LATE MODEL LINCOLNS (E.G. AIR SUSPENSION AND VSM).

USE ENHANCED AUDI AND VW FOR '99 - '05 FORD OF EUROPE GALAXY NON-ECM OR PATS SUPPORT.

USER'S MANUAL

DO NOT USE ON '96 - '03 VILLAGER, DAMAGE TO THE CONNECTOR MAY OCCUR.
